| RANGE OF OPERATION | |
| Boom length | 4500mm |
| Arm length | 2200mm |
| Maximum digging reach | 8050mm |
| Maximum digging depth | 4900mm |
| Maximum digging force | 90KN |
| Maximum digging height | 8750mm |
| Maximum dumoing height | 6150mm |
| Back-end radius of gyration | 2250mm |
| DIMENSIONS | |
| (Length*width*height)Transport dimensions | 7500*2500*3000mm |
| Axle base | 2750mm |
| Track gauge | 1900mm/1900mm |
| Ground clearance of counterweight | 1260mm |
| Min ground clearance | ≥310mm |
| TECH PERFORMANCE AND SPECIFICATION | |
| Angle of rotation | 360° |
| Machine weight | 13500kg |
| Engine model | YUCHAI(IV) |
| Rated power | 129kw |
| Rated speed | 2200r/min |
| Hydraulic system working pressure | 32Mpa |
| Hydranlic system flow | 290L/min |
| Variable piston pump | 145ml/r |
| Walking speed(高速/低速)(High speedlow speed) | 30km/h |
| Max hauling force | 76.5KN |
| Grade climbing ability | 58%/30° |
| Volume of bucket | 0.56m3 |
| Revolution overdrive pressure | 25Mpa |
| Fqt fuel quantity | ≥6L/h |
| Capacity of the fuel tank | 240L |
| Hydraulic tank capacity | 200L |
| 轮胎型号 | 900-20 |
