| RANGE OF OPERATION | |
| Boom length | 2650mm |
| Arm length | 1600mm |
| Maximum digging reach | 5700mm |
| Maximum digging depth | 2380mm |
| Maximum digging force | 20KN |
| Maximum digging height | 5480mm |
| Maximum dumoing height | 3800mm |
| Back-end radius of gyration | 1460mm |
| DIMENSIONS | |
| Axle base | 2000mm |
| Track gauge | 1270mm/1270mm |
| TECH PERFORMANCE AND SPECIFICATION | |
| Angle of rotation | 360° |
| Machine weight | 4500kg |
| Engine model | YANGMA(IV) |
| Rated power | 35.9kw |
| Rated speed | 2100r/min |
| Hydraulic system working pressure | 20Mpa |
| Hydranlic system flow | 90L/min |
| Variable piston pump | 45mI/r |
| Walking speed(高速/低速)(High speedlow speed) | 15km/h |
| Max hauling force | 20KN |
| Grade climbing ability | 58%/30° |
| Volume of bucket | 0.12m3 |
| Revolution overdrive pressure | 16Mpa |
| Fqt fuel quantity | 2-3L/h |
| Capacity of the fuel tank | 45L |
| Hydraulic tank capacity | 55L |
| 轮胎型号 | 700-16 |
| Full circle swinging time | 6s |
