Slag Removal Mechanism
Rotation Speed (High/Low): 44-66 r/min
Maximum Torque: 8.8 KN
Effective Length of Slag Removal Device: 4000 mm
Operating Efficiency: 40-60 m/h
Working Turning Radius: 2250 mm
Overall Dimensions
(Total Length * Total Width * Total Height) Transport Condition: 7500 * 2800 * 2920 mm
Wheelbase: 2750 mm
Track Center Distance: 1435 mm
Track Width: 450 mm
Counterweight Ground Clearance: 940 mm
Minimum Ground Clearance: 420 mm
Technical Parameters
Applicable Railway Gauge: Customized upon request
Efficiency: ≥40 pcs/h
Rotation Angle: 360°
Total Weight: 15000 kg
Engine Model: Cummins (National IV Emission Standard)
Rated Power: 154 kW
Rated Speed: 2200 r/min
Track Travel Speed: 5.5 km/h
Rail Wheel Travel Speed: 20km/h
Fuel tank capacity: 300L
Hydraulic oil tank capacity: 300L
