Tamping Mechanism
Vibration Frequency: 35-63Hz
Excitation Force: ≥21KN
Taming Depth (under concrete sleeper): ≥90mm
Rotation Angle: 45°
Efficiency: ≥2120pcs/h
External Dimensions
(Total Length * Total Width * Total Height) Transport Condition: 9700*2500*3100mm
Wheelbase: 2750mm
Tractor Wheel Wheelbase: 4450mm
Tractor Wheel Track Gauge: 1000-1700mm (Customizable)
Wheel Track (Front/Rear): 1900mm
Rear Turning Radius: 2250mm
Technical Parameters
Rotation Angle: 360°
Machine Weight: 15300kg
Engine Model: Yuchai (National IV Emission Standard)
Rated Power: 129Kw
Rated Speed: 2200rpm
Hydraulic System Working Pressure: 28Mpa
Maximum Traction Force: 76.5KN
Maximum Travel Speed: 25km/h
